Name: Taysla ev portable charger AC 32A 7kW
SKU: Phantom Plus 7KW
Availability: InStock

Description

Compact and Portable Design

Our product designers have crafted the ev portable charger with an easily rollable curved design, thereby rendering this product highly portable and eminently suitable for home usage and on-the-go charging. Moreover, our plug-and-play functionality simplifies and facilitates the utilization of the ev portable charger by customers for charging their electric vehicles.

Scheduled Charging for Cost Savings

This Portable ev portable charger is furnished with the function of timed charging, through which it can assist customers in formulating a superior charging plan. You have the option to schedule the charging of your electric vehicle during off-peak hours (for instance, at night), thereby circumventing the peak load and reducing the expenditure on electricity consumption.

Clear Display Screen

This nifty Portable ev portable charger comes with a spiffy 1.33-inch high-definition display that allows customers to keep tabs on their EV’s charging situation any time they like! You know, stuff like if the charging has kicked off, how long it’s estimated to take, the charging power, the maximum current, and loads more. With this display around, charging your EV becomes a breeze and super portable with the ev portable charger

Adjustable Current Settings

Our Portable ev portable charger also supports adjustable current settings (current range 8A-10A-13A-16A-20A-24A-32A), which ensures the product’s compatibility with the majority of electric car brands and models available in the market. Irrespective of the type of electric car you employ, we are confident that this product can fulfill your charging requirements. Additionally, the function of charging appointment also enables you to pre-book the charging time, thereby enhancing the flexibility of the charging schedule of electric vehicles.

Product Parameter

Appearance structure	Model	Phantom Plus 7KW
	Size	Control Box 2157745mm【HWD】
	Installation Method	Floor-mounted/Wall-Mounted
	Net Weight	About 3.5KG
	Cable Size	3*6mm²+0.75mm²
	Cable Length	5M or Customizable
Electrical index	Input Voltage	AC80V-260V
	Input Frequency	50Hz/60Hz
	Max Power	7KW
	Output Voltage	AC80V-260V
	Output Current	8A-10A-13A-16A-20A-24A-32A
	Standby Power	3W
Environment index	Work Humidity	5％~95％(non-condensing)
	Work Temperature	-30℃~+50℃
	Work Altitude	＜2000M
	Protection Class	Charging Gun IP56/Control Box IP66
	Standard	Type1 SAE J1772、Type2 IEC 62196-2、GB/T 20234
	Flammability rating	UL94 V2
	Certificate	CE、RoHS、FC
Functional design	Interface	Display Screen、LED Indicator Light
Functional design	Plug	CEE Stecker
Safety design	Over Curren Protection、Residual Current Protection、Ground Protection、Surge Protection、Over/Under Voltage, Frequency, Temperature Protection
Packaging specification	LWH: 414110cm【4.1KG】

Supportable Brands

Our Portable EV Charger is compatible with 99% of all electric vehicles, for other models please contact us for advice.

Supportable-Brands

Packaging

Portable Ev Charger Phantom Plus 7KW packing

Usage Precautions

Do not submerge the electric vehicle charger in water.
Do not step on,fold,or knot the cable.
Do not drop the electric vehicle charger or place heavy objects on it.
Do not place the charging cable near high-temperature objects when charging.
Do not operate the charger outside its temperature range of -25℃ to 55℃.
The power input cable should be at least 32.5mm (recommended 34mm)and equipped with a standard 16A socket.It is recommended that the power distribution be carried out by professionals.
Do not put your fingers into the charging connector when the power plug is still connected to the power source.
Do not use this electric vehicle charger when the cable is damaged.
Do not use an extension cord or adapter with this electric vehicle charger.
Do not hang the control box during charging to prevent poor con-tact and burning of the power plug.
This product has a built-in non-grounding function.Please check with the manufacturer on whether your vehicle requires grounding to avoid electric shock risk.
Plug the charger plug into the power supply first,then connect the charging gun to the vehicle to start charging.After charging,unplug the gun from the vehicle before unplugging the charger.Do not unplug while it’s live.

FAQs

What payment methods are accepted?

We generally accept Xtranfer, paypal, T/T payment methods.

How long does it take to ship an order?

We will send out the goods within 3-10 working days after receiving the payment, if you have customised requirements, the delivery time will be extended to about 30 days.

What types of EV chargers are available?

There are three main types: Level 1 (standard home outlets), Level 2 (dedicated home or public chargers), and DC fast chargers (public charging stations for rapid charging).

How to Choose a Suitable Charger?

Check the vehicle manual or open the car charging port todetermine the type of charging interface.
If Type 1 interface,choose Type 1 charger.If Type 2 interface,choose Type 2 charger.If GB/T interface,please make a note in the order and contact seller.

How soon will I receive my shipment?

For sample orders or small goods we usually use international express delivery, usually will be delivered in 7-15 working days (if encountered holidays or special circumstances may be delayed); for bulk goods we usually use sea freight, the specific time depends on the destination country and the ship schedule, may be more than a month.
